| Working Voltage | DC24V |
| Working Current | Monitoring current: ≤ 120μA Maximum operating current: ≤ 7mA |
| Wiring | Two-wire, polarity-free |
| Addressing Method | Electrical encoder |
| Address Range | 1–254 |
| Alarm Volume | 75 dB–115 dB @ 3 m (A) |
| Modulation Cycle | 4 s–5 s |
| Flash Rate | 1.5Hz–2.0Hz |
| Communication Distance | 1500 m (4921.26 ft) |
| Operating Temperature | –10°C to +55°C (+14°F to +131°F) |
| Storage Temperature | –20°C to +65°C (–4°F to +149°F) |
| Operating Humidity | ≤ 95% RH (no condensation) |
| Color | Shell: Red Lampshade: Clear white |
| Dimensions | 125 mm × 80 mm × 40 mm (4.92" × 3.15" × 1.57") |
| Weight (with base) | 118 g (0.26 lb) |
| Certifications | GB 26851-2011 |
